Product Description
Metal Man MP251IDVLCD Inverter Multi-Process Welder
The Metal Man MP251IDVLCD is a 230 Volt inverter powered wire feed welder for flux core and MIG welding, plus a DC stick welder. The Synergic LCD control allows the operator to program parameters by process, wire, material and gasses used. These parameters can be saved and recalled. This unit comes complete with a regulator, gas hose, a MIG gun, and a ground cable and clamp. An optional electrode holder (MMEH35-70-10FT) is available for DC stick welding. The optional TIG Torch (ACCT2V) is available for DC lift arc TIG welding. The MP251IDVLCD connects directly to a 230 Volt NEMA 6-50R receptacle. It is designed to weld materials as thin as 24 gauge up to 1/2" in a single pass. Optional Spool Gun (EZFSG2) is capable of welding aluminum with 4" spools of aluminum wire. The MP251IDVLCD is also capable of performing lift start DC TIG welding on steel and stainless steel materials with TIG Torch ACTT2V. Argon shielding gas and a TIG filler rod would also be required for TIG Welding.
Metal Man MP251IDVLCD Specs:
- 230 Volt, 45 Amp, 50/60 Hz, Single Phase
- No Load Voltage: 69 Volts DC
- Output Range-MIG/FLUX Core: 40 to 250 Amp DC
- Output Range-STICK: 20 to 200 Amp DC
- Output Range-TIG: 15 to 250 Amp DC
- Duty Cycle-MIG: 20% @ 250 Amp
- Duty Cycle-STICK: 20% @ 250 Amp
- Duty Cycle-TIG: 20% @ 250 Amp
- Suggested Wire: Steel, Stainless, Aluminum
- Wire Diameter: .023, .030, .035, .045
- Suggested Electrodes: E6013, E7014, E7018, Stainless Steel
- Electrode Diameter: 1/16" to 5/32"
- Dimensions: 24 1/8" x 11 7/8" x 18 3/4"
- Weight: 72 lbs
